2.3 Base Units
Appearance and Part Names
2-14
2.3
Base Units
The Base Unit is used to mount Optional Modules. There are three models of Base Units, a three-slot
model, a five-slot model, and an eight-slot model.
This section shows the appearance and part names of the Base Unit and describes the connector.
Appearance and Part Names
The following figure shows the appearance of the Base Unit and a part name.
Connector
The Base Unit has a Unit connector.
Unit Connector
This connector is used to connect the next Unit.
Refer to the following manual for details on connecting Units.
MP2000/MP3000 Series Machine Controller System Setup Manual (Manual No.: SIEP C880725 00)
Unit connector
