1.1 Definition of Terms
Unit Numbers
1-7
1
Introduction
Unit Numbers
The MPE720 automatically assigns Unit numbers to the Units on each Rack so that the Units can be iden-
tified.
Numbers 1 to 5 are assigned to the Units in order from the left.
Slot Numbers
The MPE720 automatically assigns slot numbers to the slots on the Base Unit so that the slots can be iden-
tified.
Numbers 1 to 9* are assigned to the slots in order from the left.
* The highest slot number depends on the specifications of the Base Unit.
