2.4 Rack Expansion Interface Unit
Connectors
2-17
2
Appearances and Parts
Connectors
The Rack Expansion Interface Unit has two connectors: Rack Expansion Interface Unit connector and
Unit connector.
Rack Expansion Interface Unit Connector
This connector is used to connect an Expansion Rack.
The Main Rack Expansion Interface Unit has three connectors (port 1, port 2, and port 3), and the Expan-
sion Rack Expansion Interface Unit has one connector (port 1).
Unit Connector
This connector is used to connect the next Unit.
Refer to the following manual for details on connecting Units.
MP2000/MP3000 Series Machine Controller System Setup Manual (Manual No.: SIEP C880725 00)
