4.3 CPU Unit Specifications
System Register Specifications
4-20
 System Error Status
The data in these registers give the error status of the system.
H Scan
Exceeded
Counter
SW00044 H Scan Exceeded Count
L Scan
Exceeded
Counter
SW00046 L Scan Exceeded Count
Reserved for
system.
SW00047
SB000470 to
SB00047F
Reserved for system. −
Hardware Con-
figuration Sta-
tus
SW00048
SB000480 D-RST
Mode switch 1 setting status:
0: OFF, 1: ON
SB000481 LOAD
SB000482 CNFG
SB000483 INIT
SB000484 E-INIT
SB000485 STOP
SB000486 Reserved for system. −
SB000487 Battery Alarm −
SB000488,
SB000489
Reserved for system. −
SB00048A MNT
Mode switch 2 setting status:
0: OFF, 1: ON
SB00048B TEST
SB00048C E-PM1
SB00048D E-PM0
SB00048E,
SB00048F
Reserved for system. −
Reserved for
system.
SW00049 Reserved for system. −
Name
Register
Address
Contents
32-bit Error Code
SW00050
0001 hex Watchdog timeout error
0051 hex Module synchronization error
0052 hex
Main CPU Unit System Down Detection (Sub
CPU Units only)
SW00051 For system error analysis
32-bit Error Address
SW00052 and
SW00053
For system error analysis
Program Error Task SW00054
0000 hex system
0001 hex DWG.A
0002 hex DWG.I
0003 hex DWG.H
0005 hex DWG.L
Continued on next page.
Continued from previous page.
Name Register Address Contents
