4.3 CPU Unit Specifications
System Register Specifications
4-22
User Operation Error Status
The data in these registers give details when an operation error occurs in a user program.
Error Data
SW00060 and
SW00061
Reserved for system.
SW00062 to
SW00065
Name of task that caused the error
SW00066 and
SW00067
Reserved for system.
SW00068 Year When Error Occurred
SW00069 Month When Error Occurred
SW00070 Day of Week When Error Occurred
SW00071 Day When Error Occurred
SW00072 Hour When Error Occurred
SW00073 Minutes When Error Occurred
SW00074 Seconds When Error Occurred
SW00075 Milliseconds When Error Occurred
SW00076 xyzz hex
Slot Where the Module Synchronization Error
Was Detected (x: Rack number from 1 to 7, y:
unit number from 1 to 4, zz: slot number from
01 to 09)
SW00077 to
SW00079
Reserved for system.
Drawing Type Error Description Register Address Contents
DWG.A
Error Count SW00080 • Error Count
Gives the number of errors that have occurred.
• Error Code
Gives the details of the error.
0 hex: Operation error
User Operation Error Code
−
1: Operation
Errors (page 4-23)
x hex (x = 1, 2, 3): Index error
User Operation Error Code
−
2: Index Errors
(page 4-24)
Error Code SW00081
DWG.I
Error Count SW00082
Error Code SW00083
DWG.H
Error Count SW00084
Error Code SW00085
Reserved for system.
SW00086,
SW00087
DWG.L
Error Count SW00088
Error Code SW00089
Continued from previous page.
Name
Register
Address
Contents
To Next Page
