4.3 CPU Unit Specifications
System Register Specifications
4-29
Module Information
The data in these registers give hardware information about the CPU Unit and Optional Modules on Racks
1 to 4.
Name Register Address Remarks
CPU Unit
Information
SW00800 CPU Module ID
SW00801 Hardware version (BCD)
SW00802 Software version (BCD)
SW00803 Number of sub-slots (hex)
SW00804 Function Module 1 ID (hex)
SW00805 Function Module 1 Status
SW00806 Function Module 2 ID (hex)
SW00807 Function Module 2 Status
SW00808 Function Module 3 ID (hex)
SW00809 Function Module 3 Status
SW00810 Function Module 4 ID (hex)
SW00811 Function Module 4 Status
SW00812 Function Module 5 ID (hex)
SW00813 Function Module 5 Status
SW00814 Function Module 6 ID (hex)
SW00815 Function Module 6 Status
Optional Module
Information
SW00816
Rack 1 Unit 1
Slot 1
Module ID
SW00817 Hardware version (BCD)
SW00818 Software version (BCD)
SW00819 Number of sub-slots
SW00820 ID of Function Module 1
SW00821 Status of Function Module 1
SW00822 ID of Function Module 2
SW00823 Status of Function Module 2
SW00824 to SW00831 Slot 2 Same as above.
SW00832 to SW00839 Slot 3 Same as above.
SW00840 to SW00847 Slot 4 Same as above.
SW00848 to SW00855 Slot 5 Same as above.
SW00856 to SW00863 Slot 6 Same as above.
SW00864 to SW00871 Slot 7 Same as above.
SW00872 to SW00879 Slot 8 Same as above.
Reserved for system. SW00880 to SW01095 −
Continued on next page.
