4.3 CPU Unit Specifications
System Register Specifications
4-67
4
Specifications
 Product information
The data in these registers give information on the CPU Unit.
 Unit and Rack Information
The data in these registers give hardware information on the Racks and Units for Racks 1 and 5 to 7.
 Register Configuration
Name Register Address Remarks
Serial ID Information
SW20000
CPU Unit serial ID (15 ASCII characters +
NULL character)
SW20001
SW20002
SW20003
SW20004
SW20005
SW20006
SW20007
SW20008 to
SW20015
Reserved for system.
Reserved for system.
SW20016 to
SW22063
−
Name
Register
Address
Remarks
Unit and
Rack
Information
SW23000
Rack 1
0: Rack not mounted, 1: Rack mounted
SW23001
Rack Status
Refer to the following section for details.
 Rack Status Details (page 4-68)
SW23002 to
SW23007
Reserved for system.
SW23008
Rack Expansion
Interface Unit
Unit ID (Low)
SW23009 Unit ID (High)
SW23010
Unit Status
Refer to the following sections for details on the
Unit status.
 Unit Status Details (page 4-68)
SW23011 Reserved for system.
SW23012 to
SW23015
Power Supply
Unit
Same as above.
SW23016 to
SW23019
CPU Unit Same as above.
SW23020 to
SW23023
Unit 1 Same as above.
SW23024 to
SW23027
Unit 2 Same as above.
SW23028 to
SW23031
Unit 3 Same as above.
SW23032 to
SW23035
Unit 4 Same as above.
SW23036 to
SW23039
Unit 5 Same as above.
Continued on next page.
