4.3 CPU Unit Specifications
System Register Specifications
4-69
4
Specifications
 Data Logging Execution Status
The data in these registers give the execution status of data logging.
Name Register Address Remarks
Data Logging Definition Existence SW24000
SB240000
0: Logging 1 definition does not exist,
1: Logging 1 definition exists
SB240001
0: Logging 2 definition does not exist,
1: Logging 2 definition exists
SB240002
0: Logging 3 definition does not exist,
1: Logging 3 definition exists
SB240003
0: Logging 4 definition does not exist,
1: Logging 4 definition exists
SB240004 to
SB24000F
Reserved for system.
Data Logging Execution Status SW24001
SB240010
0: Logging 1 is in progress,
1: Logging 1 is stopped
SB240011
0: Logging 2 is in progress,
1: Logging 2 is stopped
SB240012
0: Logging 3 is in progress,
1: Logging 3 is stopped
SB240013
0: Logging 4 is in progress,
1: Logging 4 is stopped
SB240014 to
SB240017
Reserved for system.
SB240018
0: Logging 1 is not waiting for trigger
condition,
1: Logging 1 is waiting for trigger con-
dition
SB240019
0: Logging 2 is not waiting for trigger
condition,
1: Logging 2 is waiting for trigger con-
dition
SB24001A
0: Logging 3 is not waiting for trigger
condition,
1: Logging 3 is waiting for trigger con-
dition
SB24001B
0: Logging 4 is not waiting for trigger
condition,
1: Logging 4 is waiting for trigger con-
dition
SB24001C to
SB24001F
Reserved for system.
Continued on next page.
