H2: Multi-Function Digital Outputs
79 Brake Feedback
Used for brake supervision and detection of incorrect operation.
<1> Motor Contactor Feedback (H1- = 56) = Normally open (N.O.).
<2> Brake Feedback (H1- = 79) = Normally open (N.O).
No.(Addr.) Name Description Setting
H2-01
(40BH)
Terminals M1-M2 Function
Selection (relay)
Refer to the table below for a description of setting values.
Default: 50
Min: 0
Max: 161
H2-02
(40CH)
Terminals M3-M4 Function
Selection (relay)
Default: 51
Min: 0
Max: 161
H2-03
(40DH)
Terminals M5-M6 Function
Selection (relay)
Default: 6
Min: 0
Max: 161
H2-04
(40EH)
Terminal P1-C1 Function
Selection (photocoupler)
Default: 37
Min: 0
Max: 161
H2-05
(40FH)
Terminal P2-C2 Function
Selection (photocoupler)
Default: F
Min: 0
Max: 161
H2 Multi-Function Digital Output Settings
H2-
Setting
Function Description
0 During Run
Closed: An Up/Down command is active or voltage is output.
1 Zero Speed
Open: Output speed is greater than the value of E1-09 (Minimum Output Frequency) or S1-01 (Zero
Speed Level at Stop).
Closed: Output frequency is less than or equal to the value of E1-09 (Minimum Output Frequency)
or S1-01 (Zero Speed Level at Stop).
2 Speed Agree 1
Closed: Output speed equals the speed reference (plus or minus the hysteresis set to L4-02).
3 User-set Speed Agree 1
Closed: Output speed and speed reference equal L4-01 (plus or minus the hysteresis set to L4-02).
4 Speed Detection 1
Closed: Output speed is less than or equal to the value in L4-01 with hysteresis determined by L4-02.
5 Speed Detection 2
Closed: Output speed is greater than or equal to the value in L4-01 with hysteresis determined by
L4-02.
6 Drive Ready (READY)
Closed: Power up is complete and the drive is ready to accept an Up/Down command.
7 DC Bus Undervoltage
Closed: DC bus voltage is below the Uv trip level set in L2-05.
8 During Baseblock (N.O.)
Closed: Drive has entered the baseblock state (no output voltage).
