B Parameter Table
216 YASK AWA TOEPYAIL1E01A YASKAWA AC Drive L1000E Quick Start Guide
U6-25
(6BH)
Feedback Control Output
Output monitor for the speed control loop.
10 V: Motor
secondary rated
current
(-10 to +10 V)
0.01%
U6-26
(6CH)
Inertia Compensation
Output
Output monitor for Inertia Compensation.
10 V: Motor
secondary rated
current
(-10 to +10 V)
0.01%
U6-56
(7C3H)
Speed Feedback
Compensation Output
Displays observed speed when n5-07=1 or 2.
10 V: Max output
frequency
0.01%
U6-80
to U6-99
(7B0 to
7B9,
7F0 to
7F9H)
Option Monitor 1 to 20
Monitors reserved to display data from option cards.
No signal output
available
–
<9> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
No.
(Addr.)
Name Description
Analog Output
Level
Unit
common
_
CLV
CLV/PM
V/f OLV
common
_
CLV
CLV/PM
V/f OLV
common
_
CLV
CLV/PM
V/f OLV
All Modes
