3 Electrical Installation
YASKAWA Europe TOEP C710616 92D AC Drive L1000H Quick Start Guide EN 11
 Wiring Specification
 Main Circuit
Use the fuses and line filters listed in the table below when wiring the main circuit. Do not to exceed the given tightening
torque values.
Tightening Torque Values
Tighten the main circuit terminals using the torque values provided in the table below.
 Control Circuit
The control terminal board is equipped with screwless terminals. Always use wires within the specifications listed below.
For safe wiring, YASKAWA recommends solid wires or flexible stranded wires with ferrules. Use ferrules with a length
of 8 mm.
 EMC Filter Installation
This drive has been tested in accordance with European standards IEC/EN 61800-3. In order to comply to the EMC
standards, wire the main circuit as described below.
1.
Install an appropriate EMC noise filter to the input side. See the table in Main Circuit on page 11 or refer to the
Technical Manual for details.
2. Place the drive and EMC noise filter in the same enclosure.
3. Use braided shield cable for motor and control circuit wiring.
4. Remove any paint or dirt from ground connections for minimal ground impedance.
Model
CIMR-L
EMC Filter
Main Fuse
[Bussmann]
Recom.
Motor Cable
(mm
2
)
Main Circuit Terminal Sizes
Manufacturer:
Schaffner
Manufacturer:
Block
R/L1,S/L2,T/L3,
U/T1,V/T2,W/T3, –,
+1, +2
+3 B1, B2
40005
FS5972-18-07
FB-40008A FWH-70B
2.5
M4
–
M4
M4
40006
40009 FB-40014A FWH-90B
40015
FS5972-35-07
FB-40025A
FWH-80B
M5
40018 FWH-100B 4
40024
FB-40044A
FWH-125B
6M5
M5 M640031
FS5972-60-07
FWH-200B
40039
FB-40060A
FWH-250A
16
M6
40045
M8
M8
M8
40060
FS5972-100-35
FB-40072A
25
40075
FB-40105A M8 –
40091
FS5972-170-35
35
40112
FB-40170A
FWH-350A 50
M10 M10 – M10
40150 FWH-400A 70
Terminal Size M4 M5 <1> M6 M8 M10
Tightening Torque (Nm)
<1> The tightening torque differs for the following terminals.
For use with CIMR-L4A0024 and 4A0031
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, –, +1, +2: 3.6 to 4.0 Nm
B1, B2: 2.7 to 3.0 Nm
1.2 to 1.5 2.0 to 2.5 4.0 to 6.0 9.0 to 11.0 18.0 to 23.0
Wire Type Wire Size (mm
2
)
Solid 0.2 to 1.5
Stranded 0.2 to 1.0
Stranded wire with ferrule 0.25 to 0.5
