12 MECHATROLINK-III Network Topologies
22 YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7
 Star Connections
Star connections allow you to connect slave stations through Hub Modules. Each port on a Hub Module connects to only
one slave station. You can also connect one additional Hub Module to the first Hub Module.
Note: 1. Terminating resistors are not required.
2. The maximum number of stations that you can connect with star connections depends on the communications cycle.
CPU Unit
Hub Module
Hub Module
