1 Basic Units
YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7 5
1 Basic Units
“Basic Unit” is a collective term that refers to the modules in the following table.
The Basic Modules are typically connected as shown in the following examples.
Unit Name Primary Function
CPU Module
Stores the module definitions and programs, and interprets the programs. The CPU Module also controls the
Optional Modules.
Base Unit Contains the power supply and provides the backplane to which Modules are mounted.
CPU Module
+
Base Unit
