YASKAWA MP3300iec User Manual

3 Component Part Numbers
YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7 7
3 Component Part Numbers
System Components
Type Part Number Description
CPU
PMC-U-MP33004 CPU, MP3300, 4 axis, 400 MHz, 4MB SRAM
PMC-U-MP33008 CPU, MP3300, 8 axis, 400 MHz, 4MB SRAM
PMC-U-MP33020 CPU, MP3300, 20 axis, 400 MHz, 4MB SRAM
PMC-U-MP33320 CPU, MP3300, 20 axis, 800 MHz, 8MB SRAM
PMC-U-MP33332 CPU, MP3300, 32 axis, 800 MHz, 8MB SRAM
Base Unit
JEPMC-BU3304-E Base Unit with DC Power Supply, 1 Slot, MP3300iec
JEPMC-BU3303-E Base Unit with DC Power Supply, 3 Slots, MP3300iec
JEPMC-BU3302-E Base Unit with DC Power Supply, 8 Slots, MP3300iec
JEPMC-BU3301-E Base Unit with AC Power Supply, 8 Slots, MP3300iec
Option Card
JAPMC-AN2300 Analog Inputs (AI-01)
JAPMC-AN2310-E Analog Outputs (AO-01)
JAPMC-DO2300 Digital Output Module (DO-01)
JAPMC-IO2300-E Digital I/O Module (LIO-01)
JAPMC-IO2301-E Digital I/O Module (LIO-02)
JAPMC-IO2303 Digital I/O Module (LIO-04)
JAPMC-IO2304 Digital I/O Module (LIO-05)
JAPMC-IO2305-E Digital Multi-Function I/O Module (LIO-06)
JAPMC-CM2301-E Ethernet & RS232C Communication (218IF-Y1)
MECHATROLINK
Network
JEPMC-MT2000-E HUB, MECHATROLINK-III NETWORK, 8 SLAVE PORTS
JEPMC-MT2020-E ADAPTER, ETHERNET TO MECHATROLINK
JEPMC-MTD2310-E I/O MODULE, MECHATROLINK NETWORK, 64 IN, 64 OUT
JEPMC-MTA2900-E ANALOG MODULE, MECHATROLINK NETWORK, 8 INPUT
JEPMC-MTA2910-E ANALOG MODULE, MECHATROLINK NETWORK, 4 OUTPUT
MECHATROLINK
Cables
JEPMC-W6012-A2-E MECHATROLINK-III CABLE, 0.2 M
JEPMC-W6012-A5-E MECHATROLINK-III CABLE, 0.5 M
JEPMC-W6012-01-E MECHATROLINK-III CABLE, 1.0 M
JEPMC-W6012-02-E MECHATROLINK-III CABLE, 2.0 M
JEPMC-W6012-03-E MECHATROLINK-III CABLE, 3.0 M
JEPMC-W6012-04-E MECHATROLINK-III CABLE, 4.0 M
JEPMC-W6012-05-E MECHATROLINK-III CABLE, 5.0 M
JEPMC-W6012-10-E MECHATROLINK-III CABLE, 10 M
JEPMC-W6012-20-E MECHATROLINK-III CABLE, 20 M
JEPMC-W6012-30-E MECHATROLINK-III CABLE, 30 M
JEPMC-W6012-40-E MECHATROLINK-III CABLE, 40 M
JEPMC-W6012-50-E MECHATROLINK-III CABLE, 50 M
Accessories
JEPMC-BA3001 Replacement Battery
JEPMC-OP2300 Option Slot Cover
JEPMC-OP3001 Replacement Power Supply Side Cover
JEPMC-OP3002 Replacement Option Base Side Cover
