YASKAWA MP3300iec User Manual

23 Option Module – 218IF-Y1
YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7 73
23 Option Module – 218IF-Y1
 Outline of Functions
The 218IF-01 Module has an RS-232C serial interface and an Ethernet interface mounted in it. Personal computers, HMI
devices, and controllers manufactured by other companies can be connected to the 218IF-01 Module via the serial or
Ethernet connectors.
 Hardware
 Functional Specification
 Indicators
Item Specifications
Name 218IF-Y1
Model JAPMC-CM2301-E
Communication Ports
RS-232C 1 port (PORT)
Ethernet 1 port (10Base-T)
Indicators
Module status LED indicators
RUN (green), ERR (red), STRX (green), COL (red), TX (green), RX (green)
Switches
INIT
TEST
Dimensions (mm) 125 × 95 (H × D)
Mass 85 g
Item 218IF-Y1
Interface RS-232 D-sub 9 Ethernet RJ-45
Transmission distance 15 m 100 M/segment (500m in total extension)
Transmission speed Configurable between 9600 and 57600 bps. 10 Mbps
Access method Start-stop synchronization IEEE802.3
Frame format - Ethernet Ver.2 (DIX specification)
Connection type - TCP/UDP/IP/ARP
Connection status 1:1 1:N
Transmission format
Data bit length: 5, 6, 7, or 8 Bit
Stop bit: 1 or 2 Bit
Parity bit: none, odd, or even
-
Reference Light Name Display Color State When Lit Remarks
D1
RUN Green normally operation Software control (Out port)
ERR Red Error condition Software control (Out port)
D2
STRX Green
Sending and receiving RS-232
data.
Hardware control (LAN controller)
COL Green Ethernet collision Hardware control (LAN controller)
D3
TX Green Transmitting Ethernet data. Hardware control (LAN controller)
RX Green Receiving Ethernet data. Hardware control (LAN controller)
