6 YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7
2 System Configuration Example
2 System Configuration Example
The following figure shows a typical system configuration.
PC
218IF-Y1
RS-232C
Ethernet
LIO-01
LIO-02
LIO-04
LIO-05
DO-01
LIO-06
AI-01
AO-01
I/O
MECHATROLINK-III
 Battery
 MP3300
 Front cover
for unused slot
HUB
MotionWorks IEC version
3.0.0 or higher
Optional Modules
Communications Modules
MECHATROLINK-III Cable

SERVOPACK with
MECHATROLINK-III
Communications
 I/O Module with
MECHATROLINK-
III
Communications
Servomotor
Servomotor
Servomotor
Up to 62 stations, including I/O
I/O Modules
External outputs
External inputs
Another PLC
 Ethernet communications cables
 RLYOUT
connector cable
24-VDC power
supply, AC power
supply, or status
monitoring device
 Power supply cable
24-VDC power
supply or AC
power supply
