6 Installation and Usage Conditions
YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7 13
6 Installation and Usage Conditions
This section describes installation and usage conditions for the MP3300iec Series Machine Controllers.
Install the MP3300iec Series Controllers in an environment with the following conditions.
Installation and Usage Conditions
Table 1 MP3300iec Installation and Usage Conditions
Item Specification
Environmental
Conditions
Ambient Operating
Temperature
0 to 60°C (Forced cooling is required if 55°C is exceeded.)
Ambient Storage Temperature -25 to 85°C
Ambient Operating Humidity 10% to 95% RH (with no condensation)
Ambient Storage Humidity 10% to 95% RH (with no condensation)
Pollution Level Conforms to JIS B 3502 Pollution Degree 2.
Corrosive Gas There must be no combustible or corrosive gas.
Operating Altitude 2,000 m max.
Mechanical
Operating
Conditions
Vibration Resistance
Conforms to JIS B 3502.
Continuous vibration: 5 to 9 Hz with single-amplitude of 1.75 mm
9 to 150 Hz with fixed acceleration of 4.9 m/s
2
Intermittent vibration: 5 to 9 Hz with single-amplitude of 3.5 mm
9 to 150 Hz with fixed acceleration of 9.8 m/s
2
10 sweeps each in X, Y, and Z directions for both intermittent and continuous vibration
Shock Resistance
Size of shock: Peak acceleration of 147 m/s
2
(15 G)
Duration: 11 ms
3 times each in X, Y, and Z directions
Electrical
Operating
Conditions
Noise Resistance
Conforms to EN 61000-6-2, EN 61000-6-4, and EN 55011 (Group 1 Class A).
Power supply noise (FT noise): ±2 kV min. for one minute
Radiation noise (FT noise): ±1 kV min. for one minute
Ground noise (impulse noise): ±1 kV min. for 10 minutes
Electrostatic noise (contact discharge method): ±6 kV or more, 10 times
Installation
Conditions
Ground Ground to 100 max.
Cooling Method Natural cooling or forced-air cooling. Refer to Control Panel Cooling Method on page 14
