4 Base Units
4 Base Units
The Base Unit provides the backplane to which Modules are mounted and supplies the required power to the Modules.
There are three models of Base Units, a one-slot model, a three-slot model, and an eight-slot model. This section shows
the appearance and part names of the Base Unit and describes the connector.
 Appearance and Part Names
Figure 1 illustrates the appearance of the Base Unit and a part name.
Figure 1
Figure 1 Base Unit
RLYOUT connector
Power connector
