YASKAWA MP3300iec User Manual

23 Option Module – 218IF-Y1
74 YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7
 Switch Settings
All switches on the 218IF-Y1 card must remain off.
 Connector Table
 Port Connector (CN1)
 Ethernet Connector (CN2)
Reference Switch Name State Operational mode Default Setting Remarks
S1_4 -
ON Reserved
OFF
reserved
OFF Usually reserved
S1_3 -
ON
Reserved OFF reserved
OFF
S1_2 INIT
ON Forced IP address
OFF reserved
OFF
Use IP settings stored
on controller.
S1_1 TEST
ON
Reserved OFF reserved
OFF
Item Type Names of Parts and Maker
Use connector D-sub 9pin Socket 17LE-13090-27D2BC)-FA (DDK)
Engagement
connector
D-sub 9pin Plug 17JE-23090-02(D8B) Another (DDK)
Pin layout
Number Signal name I/O Remarks Number Signal name I/O Remarks
1 FG O Protective ground 6 DR I Transmission control
2 SD O Transmission data 7 GND P Signal ground
3 RD I Received data 8 - - -
4 RS O Transmission request 9 ER O Data terminal ready
5CS I
It is possible to
transmit
RS-232C cable for MP2xxx
JEPMC-W5311-**
Item Type Names of Parts and Maker
Use connector RJ-45 (cat.5) 5555153-1 (Tyco AMP)
Engagement
connector
RJ-45 (cat.5) Plug
Pin layout
Number Signal name I/O Remarks Number Signal name I/O Remarks
1 TXD+ I/O
Transmission data +
side
5- --
2 TXD- O
Transmission
data?Side
6 RXD- I Received data side
3 RXD+ O Receive data + side 7 - - -
4- -- 8 - --
