21 Option Module - LIO-04/05 Modules
56 YASKAWA America, Inc. MP3300iec Hardware Manual YAI-SIA-IEC-7
6 Orange — — DICOM_2/4 P/P Digital Input common 2/4
7
Gray — — DI_08/24 I/I Digital input 8/24
8 White — — DI_10/26 I/I Digital input 10/26
9
Yell ow — — DI_12/28 I/I Digital input 12/28
10
Pink — — DI_14/30 I/I Digital input 14/30
11
Orange — — — N.C.
12
Gray — — — DO_00/16 O/O Digital output 0/16
13 White — — — DO_02/18 O/O Digital output 2/18
14
Yell ow — — — N.C.
15
Pink — — — +24V_1/3 P/P Digital output 24V supply 1/3
16 Orange — — — — DO_04/20 O Digital output 4/20
17
Gray — — — — DO_06/22 O Digital output 6/22
18 White — — — — N.C.
19
Yell ow — — — — DO_08/24 O/O Digital output 8
20
Pink — — — — DO_10/26 O/O Digital output 10
21
Orange — — — — Continuous N.C.
22 Gray — — — — Continuous +24V_2/4 P Digital Output 24V supply 2/4
23 White — — — — Continuous DO_12/28 O Digital output 12/28
24
Yell ow — — — — Continuous DO_14/30 O Digital output 14/30
25 — — — — Continuous N.C.
26
Orange —N.C.
27 Gray — DI_01/17 I/I
Digital input 1/17
(shared with interrupt input)
28 White — DI_03/19 I/I Digital input 3/19
29
Yell ow — DI_05/21 I/I Digital input 5/21
30
Pink — DI_07/23 I/I Digital input 7/23
31
Orange — — N.C.
32 Gray — — DI_09/25 I/I Digital input 9/25
33 White — — DI_11/27 I/I Digital input 11/27
34
Yell ow — — DI_13/29 I/I Digital input 13/29
35 Pink — — DI_15/31 I/I Digital input 15/31
36
Orange — — — N.C.
37
Gray — — — DO_01/17 O/O Digital output 1/17
38 White — — — DO_03/19 O/O Digital output 3/19
39
Yell ow — — — 0V_1/3 P/P Digital Output 0VDC common 1/3
40
Pink — — — N.C.
41 Orange — — — Continuous DO_05/21 O/O Digital output 5/21
42
Gray — — — Continuous DO_07/23 O/O Digital output 7/23
43 White — — — Continuous N.C.
44
Yell ow — — — Continuous DO_09/25 O/O Digital output 9/25
45
Pink — — — Continuous DO_11/27 O/O Digital output 11/27
46
Orange — — — — 0V_2/4 P/P Digital Output 0VDC common 2/4
47 Gray ———————— N.C.
48 White ———————— DO_13/29 O/O Digital output 13/19
49
Yell ow ———————— DO_15/31 O/O Digital output 15/31
50
Pink ———————— N.C.
DANGER
Columns “Signal Name”, “I/O”, and “Function” display the values for connectors CN1 and CN2 in the format “CN1/
CN2” respectively.
Pin Wire Color Markings Signal Name I/O Function
