Basic Specifications
2.2.1
260IF Module
2-4
2
2.3 Switch Specifications
Refer to 4.1 Basic Use of the 260IF Module for setting details.
SW1
The baud rate for DeviceNet communications and Slave/Master settings are made on this
DIP switch.
Table 2.1 SW1 Specifications
SW2 and SW3
These rotary switches are used to set the DeviceNet MAC ID.
Table 2.2 SW2 and SW3 Specifications
Pin Meaning Setting
DR0 DeviceNet
baud rate
DR1 DR0
OFF OFF 125 kbps (default)
DR1 OFF ON 250 kbps
ON OFF 500 kbps
ON ON (Do not change)
X1 Slave/Master setting OFF Slave (default)
ON Master
X2 Not used Always OFF
Switch Meaning Setting
*10 (SW2) MAC ID 10’s digit 0 to 6 Set a two-digit local node MAC ID (0 to 63) in
decimal using two rotary switches (default: 00).
*1 (SW3) MAC ID 1’s digit 0 to 9
