YASKAWA P1000 Series

CIMR - P U 4 T
0675 U
A A
Drive
P1000
Series
Letter
Enclosure
Type
Design
Revision
Order
Letter
Region
Code
USA
No. Voltage Class
Letter
Environmental
Specification
A Standard
380-480 Vac 4
Customized
Specification
6-Phase/
12-Pulse Input
<2>
A
Refer to the tables below
Flange Type
U
<1>
U
Open Type
(Non-Flange)
<1> Provides method of mounting drive with backside (heatsink) external to enclosure with NEMA 12 integrity.
<2> Drives with these specifications do not guarantee complete protection for the environmental conditions indicated.
n
6-Phase/12-Pulse 400 V Class Rated Output
Table 1 Model Number and Specifications (400 V Class)
Drive Model Max. Motor Capacity kW (HP) Rated Output Current A
4T0058o
30 (40) 58
4T0072o
37 (50) 72
4T0088o
45 (60) 88
4T0103o
55 (75) 103
4T0139o
75 (100) 139
4T0165o
90 (125) 165
4T0208o
110 (150) 208
4T0250o
132 (200) 250
4T0296o
160 (250) 296
4T0362o
185 (300) 362
4T0414o
220 (350) 414
4T0515o
250 (400-450) 515
4T0675o
355 (500-550) 675
