YASKAWA P1000 Series User Manual

u
Gasket Replacement for Flange Type Enclosures
n
Gasket Replacement Procedure
1.
Use a plastic scraper to remove the damaged or torn gasket without scratching the mounting surfaces.
2.
Peel off the adhesive cover from the replacement gasket.
3.
Align the holes on the mounting flange or fan bracket with the holes on the replacement gasket and apply the new
gasket.
n
Gasket Replacement Parts
Each replacement part contains two gaskets in the event that a gasket is torn during application.
Contact a Yaskawa representative or the nearest Yaskawa sales office to order replacement gaskets as required.
Table 7 Gasket Replacement Part Numbers
Drive Model Replacement Part Part Number
4T0058U Mounting Flange Gasket UGK00418-A
4T0072U Mounting Flange Gasket UGK00419-A
4T0088U
4T0103U
Mounting Flange Gasket UGK00420-A
4T0139U
4T0165U
Fan Bracket Gasket UGK00421-A
4T0208U Fan Bracket Gasket UGK00422-A
4T0250U
4T0296U
4T0362U
Fan Bracket Gasket UGK00423-A
4T0414U Fan Bracket Gasket UGK00424-A
4T0515U
4T0675U
Fan Bracket Gasket UGK00425-A
7 Periodic Inspection & Maintenance
38
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
