YASKAWA P1000 Series User Manual

u
External Mounting and Panel Cutout Dimensions
Table 11 External Mounting and Panel Cutout Dimensions Reference
Model
External Mounting Dimensions
Page
Panel Cutout Dimensions
Page
Flange Type Models
4T0058U 46 62
4T0072U 47 63
4T0088U
48 64
4T0103U
4T0139U
49 65
4T0165U
4T0208U 50 66
4T0250U
51 674T0296U
4T0362U
4T0414U 52 68
4T0515U
53 69
4T0675U
Non-Flange Type Models
4T0058A 54 70
4T0072A 55 71
4T0088A
56 72
4T0103A
4T0139A
57 73
4T0165A
4T0208A 58 74
4T0250A
59 754T0296A
4T0362A
4T0414A 60 76
4T0515A
61 77
4T0675A
8 Specifications
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
45

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
