YASKAWA P1000 Series

1.97
[50]
1.97
[50]
4.72
[120]
4.72
[120]
1.18
[30]
1.18
[30]
(4)-1/2"
[M12]
AIR
AIR
AIR
AIR
30.43±.02 [773±0.5]
31.5±.02 [800±0.5]
14.57±.02 [370±0.5]
19.69±.02 [500±0.5]
29.13±.02 [740±0.5]
19.06±.02 [484±0.5]
CUTOUT
0.63
[16]
0.67
[17]
0.51
[13]
NOTE:
EXPOSED HEATSINK DEPTH
D=5.12" MINUS PANEL THICKNESS
0.55
[14]
℄
Unit: in. [mm]
Figure 51 Non-Flange Type Models 4T0250A to 4T0362A Clearances and Panel Cutout Dimensions
8 Specifications
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
75
