6 Drive Options and Peripheral Devices
Table 6 lists the names of the various peripheral devices, accessories, and options available for Yaskawa drives. Contact
Yaskawa or your Yaskawa agent to order these peripheral devices.
• Peripheral Device Selection: Refer to the Yaskawa catalog for selection and part numbers.
• Peripheral Device Installation: Refer to the corresponding option manual for installation instructions.
Table 6 Available Peripheral Devices
Option Model Number Description
Power Options
AC Reactor –
Protects the drive when operating from a large power supply and improves the power factor by
suppressing harmonic distortion. Highly recommended for power supplies that exceed 600 kVA.
Output Option Cards
Analog Monitor AO-A3
• Provides extra multi-function analog output terminals
• Output channels: 2
• Output voltage: -10 to 10 V, 11-bit (signed)
Communication Option Cards
EtherNet/IP SI-EN3 Connects to an EtherNet/IP network.
EtherNet/IP with DLR SI-EN3D Dual-port hardware connects to an EtherNet/IP network in a star, line or ring configuration.
Modbus TCP/IP SI-EM3 Connects to a Modbus TCP/IP network.
Modbus TCP/IP with RSTP SI-EM3D Dual-port hardware connects to a Modbus TCP/IP network in a star, line or ring configuration.
PROFINET SI-EP3 Connects to a PROFINET network.
LonWorks SI-W3 Connects to a LonWorks network.
DeviceNet SI-N3 Connects to a DeviceNet network
Metasys N2/
Apogee P1
SI-J3 Connects to a Johnson Controls Metasys N2 network or Siemens Apogee P1 network.
PROFIBUS-DP SI-P3 Connects to a PROFIBUS-DP network.
MECHATROLINK-II SI-T3 Connects to a MECHATROLINK-II network.
MECHATROLINK-III SI-ET3 Connects to a MECHATROLINK-III network.
BACnet SI-B3 Connects to a BACnet network.
EtherCAT SI-ES3 Connects to an EtherCAT network.
Interface Options
LCD Operator
JVOP-180C
JVOP-180CR
Digital operator with 8 languages, clear text LCD display, and copy function; max. cable length
for remote usage: 3 m
LED Operator JVOP-182 5-digit LED operator; max. cable length for remote usage: 3 m
Remote Operator Cable
UWR000051, 1 m cable
UWR000052, 2 m cable
RJ-45, 8-pin straight through, UTP CAT5e, extension cable (1 m or 2 m) to connect the digital
operator for remote operation.
USB Copy Unit JVOP-181
• Allows the user to copy and verify parameter settings between drives.
• Functions as an adapter to connect the drive to a USB port on a PC.
120 Vac Logic Interface DI-101 Provides for interface of 120 Vac control logic circuits.
Mechanical Options
IP20/NEMA Type 1 Kit EZZ021136A-H Parts to make the drive conform to IP20/NEMA Type 1 enclosure requirements.
IP20/NEMA Type 1, 4, 12
Blank Keypad Kit
UUX0000526
Provides digital operator functionality on an enclosure designed for IP20/NEMA Type 1, 3R, 4,
4X, 12, or IPo6 environment. This keypad has a blank label on the front.
IP20/NEMA Type 1, 4, 12
Yaskawa Logo Keypad Kit
UUX0000527
Provides digital operator functionality on an enclosure designed for IP20/NEMA Type 1, 3R, 4,
4X, 12, or IPo6 environment. This keypad has a Yaksawa brand label on the front.
Others
24 V Power Supply PS-A10HB Supplies the drive controller with 24 Vdc power during main power loss.
PC Software Tools
DriveWizard Industrial SW.DW.30 PC tool for drive setup and parameter management
