YASKAWA P1000 Series User Manual

u
Drive Watt Loss Data
Table 10 Drive Watt Loss
Drive Model
Normal Duty
Rated Amps (A)
<1>
Internal External Total
4T0058o
58 197 453 650
4T0072o
72 244 588 832
4T0088o
88 285 669 954
4T0103o
103 329 827 1156
4T0139o
139 487 1179 1666
4T0165o
165 624 1520 2164
4T0208o
208 553 1746 2299
4T0250o
250 729 2305 3034
4T0296o
296 772 2308 3080
4T0362o
362 874 3168 4042
4T0414o
414 1083 3443 4526
4T0515o
515 1474 4850 6324
4T0675o
675 1789 4861 6650
<1> Value assumes the carrier frequency is set to 2 kHz.
u
Drive Derating Data
n
Temperature Derating
To ensure the maximum performance life, the drive output current must be derated as shown in Figure 21 when the drive is
installed in areas with high ambient temperature or if drives are mounted side-by-side in a cabinet. Set parameter L8-35 to 3
for all 6-Phase/12-Pulse Flange and Non-Flange models to ensure reliable drive overload protection.
n
Parameter Settings
No. Name Description Range Def.
L8-12
Ambient
Temperature Setting
Adjust the drive overload (oL2) protection level when the drive is installed
in an environment that exceeds its ambient temperature rating.
-10 to +50 +40 °C
L8-35
Installation Method
Selection
0: IP00/Open-Chassis Enclosure
1: Side-by-Side Mounting
2: IP20/NEMA Type 1 Enclosure
3: Finless Drive or External Heatsink Installation
Note: Set this parameter to 3 for all 6-Phase/12-Pulse Flange and
Non-Flange models.
0 to 3
<1>
<1> Set this parameter to 3 for all 6-Phase/12-Pulse Flange and Non-Flange models. Default setting is determined by drive model.
Setting 0: (Models 4T0208o to 4T0675o)
Setting 2: (Models 4T0058o to 4T0165o).
Setting 0: IP00/Open-Chassis Enclosure
Drive operation between -10 °C and +50 °C allows 100% continuous current without derating.
Setting 1: Side-by-Side Mounting
Drive operation between -10 °C and +30 °C allows 100% continuous current without derating. Operation between +30 °C and
+50 °C requires output current derating.
Setting 2: IP20/NEMA Type 1 Enclosure
Drive operation between -10 °C and +40 °C allows 100% continuous current without derating. Operation between +40 °C and
+50 °C requires output current derating.
Setting 3: External Heatsink Installation, Finless Drive
Drive operation between -10 °C and +40 °C allows 100% continuous current without derating. Operation between +40 °C and
+50 °C requires output current derating.
8 Specifications
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
43

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
