YASKAWA P1000 Series User Manual

8 Specifications
u
Power Ratings for Models 4T0058o to 4T0208o
Table 8 Power Ratings for Models 4T0058o to 4T0208o
Item Specification
Drive Model
4T0058o 4T0072o 4T0088o 4T0103o 4T0139o 4T0165o 4T0208o
Maximum Applicable Motor
Capacity kW (HP)
<1>
ND Rating
30
(40)
37
(50)
45
(60)
55
(75)
75
(100)
90
(125)
110
(150)
Input
Input Current (A)
<2>
ND Rating 54 66 79 97 131 156 190
Rated Voltage
Rated Frequency
6-Phase/12-Pulse: 380 Vac to 480 Vac 50/60 Hz
Note: 6-Phase isolated supply with each of the output windings phase-shifted
by 30 electrical degrees or Hybrid 6-phase topology.
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA) ND Rating 53.0 64.9 78.6 96.0 130 156 189
Output
Rated Output
Capacity (kVA)
<3>
ND Rating
<4>
44 55 67 78 106 126 159
Rated Output
Current (A)
ND Rating
<4>
58 72 88 103 139 165 208
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User adjustable between 1 and 15 kHz
User adjustable between
1 and 10 kHz
Maximum Output Voltage (V) Three-phase: 380 to 480 Vac (proportional to input voltage)
Maximum Output Frequency (Hz) 400 Hz (user-adjustable)
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than
the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring conditions,
and power supply impedance. This input current rating is the 3-Phase total input current rating. Refer to Alternative AC Drive Branch Circuit
Protection on page 86 for the 6-Phase input current rating.
<3> Rated motor capacity is calculated with a rated output voltage of 440 V.
<4> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
8 Specifications
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
39

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
