YASKAWA P1000 Series User Manual

Drive Model Terminal
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4T0250o
R/L1, S/L2, T/L3
Refer to applicable codes for wire size M10
18 to 23
(159.3 to 203.6)
R1/L11, S1/L21, T1/L31
U/T1, V/T2, W/T3
⊖, ⊕3
22 to 1/0 (0.3 to 53.5) M6
2.5 to 3.0
(22.1 to 26.6)
Refer to applicable codes for wire size M10
18 to 23
(159.3 to 203.6)
4T0296o
R/L1, S/L2, T/L3
Refer to applicable codes for wire size
M10
18 to 23
(159.3 to 203.6)
R1/L11, S1/L21, T1/L31
U/T1, V/T2, W/3 M12
32 to 40
(283.2 to 354.0)
⊖, ⊕3
22 to 1/0 (0.3 to 53.5) M6
2.5 to 3.0
(22.1 to 26.6)
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
4T0362o
R/L1, S/L2, T/L3
Refer to applicable codes for wire size
M10
18 to 23
(159.3 to 203.6)
R1/L11, S1/L21, T1/L31
U/T1, V/T2, W/T3 M12
32 to 40
(283.2 to 354.0)
⊖, ⊕3
22 to 1/0 (0.3 to 53.5) M6
2.5 to 3.0
(22.1 to 26.6)
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
4T0414o
R/L1, S/L2, T/L3
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
R1/L11, S1/L21, T1/L31
U/T1, V/T2, W/T3
⊖, ⊕3
22 to 1/0 (0.3 to 53.5) M6
2.5 to 3.0
(22.1 to 26.6)
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
4T0515o
R/L1, S/L2, T/L3
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
R1/L11, S1/L21, T1/L31
U/T1, V/T2, W/T3
⊖, ⊕3
13.3 to 127 (6 to 250) M8
13.5 to 15
(119.5 to 132.8)
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
4T0675o
R/L1, S/L2, T/L3
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
R1/L11, S1/L21, T1/L31
U/T1, V/T2, W/T3
⊖, ⊕3
13.3 to 127 (6 to 250) M8
13.5 to 15
(119.5 to 132.8)
Refer to applicable codes for wire size M12
32 to 40
(283.2 to 354.0)
u
Wiring Checklist
No.
Item Page(s)
Drive, Peripherals, Option Cards
1 Check drive model number to ensure receipt of correct model. 12
2 Make sure you have the correct braking resistors, DC link chokes, noise filters, and other peripheral devices.
3 Check the option card model number.
Installation Area and Physical Setup
4 Ensure that the area surrounding the drive complies with specifications. 15
Power Supply Voltage, Output Voltage
3 Electrical Installation
26
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
