YASKAWA P1000 Series

Eye Bolts
with M12 Screw
146.8
(5.78)
183
(7.20)
193 (7.60) 193 (7.60) 193 (7.60) 193 (7.60)
781.2 (30.76)
670 (26.38)
370 (14.57)
3.7
(0.12)
182 (7.17)
182 (7.17)
182 (7.17)
182 (7.17)
182 (7.17)
182 (7.17)
182 (7.17)
17 (0.67)
39.1 (1.54)
1308 (51.50)
812 (31.97)
1193.2 (46.98) 1044.6 (41.13)
56.1 (2.21)
130.9 (5.15)
58.7 (2.31) 132.5 (5.22)
unit: mm (inch)
22-Mounting Holes
for M10 Screw
Figure 29 Flange Type Models 4T0515U and 4T6075U Mounting Dimensions
8 Specifications
