YASKAWA P1000 Series User Manual

Mounting Dimensions for Non-Flange Type 4TooooA Models
AIR
AIR
HORIZONTAL MTG DIM
VERTICAL MTG DIM
10.16
[258]
0.11
[3]
0.09
[2.3]
6.05
[153.6]
15.75
[400]
3.54
[90]
1.27
[32.3]
2.36
[60]
6.26
[158.9]
8.43
[214]
0.3
[7.5]
15.16
[385.0]
0.3
[7.5]
FRONT VIEW
1.08
[27.5]
7.68
[195.0]
(4)-MOUNTING HOLES
FOR 1/4"[M6] SCREWS
0.6
[15.2]
9.84
[250]
0.28
[7.1]
3.94
[100]
6.22
[158]
OPTIONAL CAPACITOR COVER
WHEN USING AN EXTERNAL MOUNT HEATSINK, UL COMPLIANCE
REQUIRES COVERING EXPOSED CAPACITORS IN THE MAIN
CIRCUIT TO PREVENT INJURY.
Unit: in [mm]
Figure 30 Non-Flange Type Model 4T0058A Mounting Dimensions
8 Specifications
54
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
