YASKAWA P1000 Series

AIR
AIR
HORIZONTAL MTG DIM
VERTICAL MTG DIM
10.16
[258]
0.11
[3]
0.09
[2.3]
6.05
[153.6]
17.72
[450]
3.54
[90]
1.57
[40]
2.36
[60]
7.24
[183.9]
FRONT VIEW
(4)-MOUNTING HOLES
FOR 1/4"[M6] SCREWS
0.6
[15.2]
9.41
[239]
0.3
[7.5]
1.19
[30.1]
8.66
[220.0]
0.3
[7.5]
17.13
[435.0]
10.83
[275]
0.28
[7.1]
0.3
[7.7]
3.94
[100]
6.22
[158]
OPTIONAL CAPACITOR COVER
WHEN USING AN EXTERNAL MOUNT HEATSINK, UL COMPLIANCE
REQUIRES COVERING EXPOSED CAPACITORS IN THE MAIN
CIRCUIT TO PREVENT INJURY.
Unit: in [mm]
Figure 31 Non-Flange Type Model 4T0072A Mounting Dimensions
8 Specifications
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
55
