YASKAWA P1000 Series

AIR
AIR
HORIZONTAL MTG DIM
VERTICAL MTG DIM
10.16
[258]
0.11
[2.7]
0.09
[2.3]
6.43
[163.3]
20.06
[509.5]
3.54
[90]
3.3
[83.8]
2.36
[60]
9.54
[242.4]
FRONT VIEW
(4)-MOUNTING HOLES
FOR 1/4"[M6] SCREWS
0.62
[15.7]
11.5
[292]
4.13
[105]
6.02
[153]
0.3
[7.5]
1.28
[32.5]
10.24
[260]
0.3
[7.5]
19.47
[494.5]
12.8
[325]
0.18
[4.6]
0.18
[4.6]
OPTIONAL CAPACITOR COVER
WHEN USING AN EXTERNAL MOUNT HEATSINK, UL COMPLIANCE
REQUIRES COVERING EXPOSED CAPACITORS IN THE MAIN
CIRCUIT TO PREVENT INJURY.
Unit: in [mm]
Figure 32 Non-Flange Type Models 4T0088A and 4T0103A Mounting Dimensions
8 Specifications
56
