YASKAWA P1000 Series User Manual

AIR
AIR
VERTICAL MTG DIM
14.57
[370]
0.15
[4]
0.18
[4.5]
7.2
[183]
50
[1270]
FRONT VIEW
(6)-MOUNTING HOLES
FOR 1/2"[M12] SCREWS
4.44
[112.7]
22.04
[559.9]
2.36
[60]
30.07
[763.9]
3.54
[90]
41.13
[1044.6]
26.38
[670]
0.24
[6]
0.24
[6]
5.91
[150]
8.66
[220]
30.76
[781.2]
4.53
[115]
8.66
[220]
8.66
[220]
HORIZONTAL MTG DIMS
0.59
[15]
0.59
[15]
OPTIONAL CAPACITOR COVER
WHEN USING AN EXTERNAL MOUNT HEATSINK, UL
COMPLIANCE REQUIRES COVERING EXPOSED
CAPACITORS IN THE MAIN CIRCUIT TO PREVENT INJURY.
48.82
[1240]
Unit: in [mm]
Figure 37 Non-Flange Type Models 4T0515A and 4T6075A Mounting Dimensions
8 Specifications
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
61

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
