YASKAWA P1000 Series

AIR
AIR
HORIZONTAL MTG DIM
VERTICAL MTG DIM
14.57
[370]
0.11
[3]
0.18
[4.5]
6.84
[173.8]
40.39
[1026]
FRONT VIEW
(4)-MOUNTING HOLES
FOR 1/2"[M12] SCREWS
3.24
[82.3]
15.35
[389.9]
2.36
[60]
23.41
[594.6]
3.54
[90]
5.32
[135]
9.25
[235]
19.69
[500]
0.3
[8]
0.3
[8]
24.06
[611.2]
2.56
[65]
14.57
[370]
33.91
[861.4]
0.55
[14]
0.51
[13]
OPTIONAL CAPACITOR COVER
WHEN USING AN EXTERNAL MOUNT HEATSINK, UL
COMPLIANCE REQUIRES COVERING EXPOSED
CAPACITORS IN THE MAIN CIRCUIT TO PREVENT INJURY.
39.33
[999]
Unit: in [mm]
Figure 36 Non-Flange Type Model 4T0414A Mounting Dimensions
8 Specifications
60
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
