YASKAWA P1000 Series

AIR
AIR
HORIZONTAL MTG DIM
VERTICAL MTG DIM
12.99
[330]
0.13
[3]
0.13
[3.2]
6
[152.5]
27.76
[705]
FRONT VIEW
(4)-MOUNTING HOLES
FOR 3/8"[M10] SCREWS
2.78
[70.5]
13.54
[343.8]
2.36
[60]
16.25
[412.7]
3.54
[90]
21.23
[539.2]
0.49
[12.5]
0.49
[12.5]
26.77
[680]
2.56
[65.1]
12.8
[325]
5.13
[130]
7.88
[200]
17.92
[455.2]
0.2
[5]
0.2
[5]
OPTIONAL CAPACITOR COVER
WHEN USING AN EXTERNAL MOUNT HEATSINK, UL
COMPLIANCE REQUIRES COVERING EXPOSED
CAPACITORS IN THE MAIN CIRCUIT TO PREVENT INJURY.
Figure 34 Non-Flange Type Models 4T0208A Mounting Dimensions
8 Specifications
58
