 Yaskawa Vendor-Specific Control and Status Words
 The Control Word and the Status Word
The contents of the Control Word and the Status Word are detailed in Table 14.
 Frequency Reference
Frequency Reference is a 16-bit word containing the desired output frequency.
 Output Frequency
Output Frequency is a 16-bit word containing the current output frequency of the drive.
Table 14 Yaskawa-Specific Control Word and Status Word
Yaskawa-Specific Control Word Yaskawa-Specific Status Word
Bit Description Bit Description
0 Run bit 0 Running
1 Reverse run bit 1 Zero Speed
2EF0 2 Reverse Operation
3Fault Reset 3 Reset Signal Input Active
4ComFref 4At Speed
5ComCtrl 5Ready
6DI3 6Alarm
7DI4 7Fault
8DI5 8oPE Fault
9DI6 9Uv Return
10 DI7 10 2nd Motor
11 Not Used 11 ZSV
12 Not Used 12 Not Used
13 Not Used 13 Not Used
14 Not Used 14 Net Reference
15 Not Used 15 Net Control
