Table 11. Differences in main circuit terminal size, shape, and wire gauge for 400 V class
Model
Drive capacity
V1000: Type
GA500: Type
Terminal
Connectable
wire gauge size:
mm
2
Terminal Screw
Tightening
torque: N-m
(lbf･in)
Size
Shape
V1000
4A0001
4A0002
4A0004
4A0005
4A0007
4A0009
4A0011
R/L1,S/L2,T/L3
2-5.5
M4
1.2 to 1.5
(10.6-13.3)
U/T1,V/T2,W/T3
-,+1,+2
B1,B2
⏚
GA500
4001
4002
4004
4005
4007
4009
R/L1,S/L2,T/L3
2-5.5
M3
0.5-0.6
(4.4-5.3)
U/T1,V/T2,W/T3
-,+1,+2
B1,B2
⏚
M4
1.2-1.5
(10.6-13.3)
4012
R/L1,S/L2,T/L3
2-5.5
M4
1.5-1.7
(13.5-15)
U/T1,V/T2,W/T3
-,+1,+2
B1,B2
⏚
1.2-1.5
(10.6-13.3)
V1000
4A0018
R/L1,S/L2,T/L3
2-14
M4
2.1 to 2.3
(18.6-20.4)
U/T1,V/T2,W/T3
-,+1,+2
B1,B2
2-5.5
⏚
2-14
M5
2.0 to 2.5
(17.7-22.1)
GA500
4018
R/L1,S/L2,T/L3
2-14
M4
1.5-1.7
(13.5-15)
U/T1,V/T2,W/T3
-,+1,+2
2-8
B1,B2
2-5.5
⏚
2-14
2.0-2.5
(17.7-22.1)
V1000
4A0023
R/L1,S/L2,T/L3
3.5-14
M4
2.1 to 2.3
(18.6-20.4)
U/T1,V/T2,W/T3
-,+1,+2
B1,B2
2-5.5
⏚
5.5-14
M5
2.0 to 2.5
(17.7-22.1)
GA500
4023
R/L1,S/L2,T/L3
3.5-14
M4
1.5-1.7
(13.5-15)
U/T1,V/T2,W/T3
-,+1,+2
2-14
B1,B2
2-5.5
⏚
5.5-14
M5
2.0-2.5
(17.7-22.1)
