YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
6/35
3. Terminal Matching Table
Carefully note that some terminals are different in size and shape between the V1000 and GA500. (See Section 3-4.)
Also, all the GA500 model types use European terminals not only in the control circuit but also in the main circuit.
Table 5: Main Circuit Terminal Matching Table
Main Circuit Terminals
Notes
V1000
GA500
V2A
0001-0069
GA50
2001-2089
GA50
B001-B018
V4A
0001-0038
GA50
4001-4060
R/L1
R/L1
For main circuit power supply input
S/L2
S/L2
T/L3
T/L3
L
N
U/T1
U/T1
U/T1
For drive output
V/T2
V/T2
V/T2
W/T3
W/T3
W/T3
B1
B1
B1
For connecting braking resistor/braking resistor unit
B2
B2
B2
+1
+1
+1
For DC reactor connection, for direct-current power supply input (positive
terminal)
+2
+2
For DC reactor connection
-
-
-
For direct-current power supply input (negative terminal), for braking unit
connection (negative terminal)
For grounding: 200 V class, D class grounding (ground to 100 Ω or less)
400 V class: C class grounding (ground to 10 Ω or less)
* The single-phase 200V-class GA500 model types are not equipped with the DC reactor connection terminals (+2).
(2 pcs)
(2 pcs)
(2 pcs)

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
