YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
30/35
6. Carrier Frequency and Rated Current Derating
The settings of A1-02 [Control Method Selection], C6-01 [Normal / Heavy Duty Selection], and C6-02 [Carrier Frequency
Selection] determine the rated current derating. Also, it may be different between the V1000 and GA500 depending on the
capacity.
If the capacity is such that the rated current is lower with the GA500 than with the V1000 (hatched in the table below), the
carrier frequency should be lowered or the GA500 capacity should be increased.
Comparison of rated output current (A): V1000 versus GA500
V1000: A1-02=0, 2, 5
GA500: A1-02=0, 2, 5
Table 21: Carrier frequency and derating at heavy duty (HD) rating - three-phase 200 V class
Heavy
duty
(HD)
rating
(kW)
Model
Derated current value (A)
C6-02=1
(2.0kHz)
C6-02=2
(5.0kHz)
C6-02=3
(8.0kHz)
C6-02=4
(10.0kHz)
C6-02=5
(12.5kHz)
C6-02=6
(15.0kHz)
CIPR-
GA50A

CIMR-
VA2A

0.1
2001
0.8
0.8
0.8
0.8
0.7
0.6
0001
0.8
0.8
0.8
0.8
0.7
0.6
0.2
2002
1.6
1.6
1.6
1.6
1.4
1.3
0002
1.6
1.6
1.6
1.6
1.4
1.3
0.6
2004
3.0
3.0
3.0
3.0
2.7
2.4
0004
3.0
3.0
3.0
3.0
2.7
2.4
0.8
2006
5.0
5.0
5.0
5.0
4.5
4.0
0006
5.0
5.0
5.0
5.0
4.5
4.0
1.1
2008
6.9
6.9
6.9
6.5
6.0
5.5
0008
6.9
6.9
6.9
6.5
6.0
5.5
1.5
2010
8.0
8.0
8.0
7.5
7.0
6.4
0010
8.0
8.0
8.0
7.5
6.9
6.4
2.2
2012
11.0
11.0
11.0
10.4
9.6
8.8
0012
11.0
11.0
11.0
10.3
9.5
8.8
3.0
2018
14.0
14.0
14.0
13.2
12.2
11.2
0018
14.0
14.0
14.0
13.1
12.1
11.2
3.7
2021
17.6
17.6
17.6
16.6
15.3
14.1
0021
17.5
17.5
17.5
16.4
15.2
14.0
5.5
2030
25.0
25.0
25.0
23.6
21.8
20.0
0030
25.0
25.0
25.0
23.5
21.7
20.0
7.5
2042
33.0
33.0
33.0
31.1
28.8
26.4
0042
33.0
33.0
33.0
31.0
28.6
26.4
11.0
2056
47.0
47.0
47.0
44.3
41.0
38.0
0056
47.0
47.0
47.0
44.1
40.7
37.6
15.0
2070
60.0
60.0
60.0
56.6
52.3
48.0
0070
60.0
60.0
60.0
56.3
52.0
48.0
18.5
2082
75.0
75.0
75.0
70.7
65.4
60.0
-
-
-
-
-
-
-

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
