Table 22: Carrier frequency and derating at heavy duty (HD) rating - three-phase 400 V class
Heavy
duty
(HD)
rating
(kW)
Model
Derated current value (A)
C6-02=1
(2.0kHz)
C6-02=2
(5.0kHz)
C6-02=3
(8.0kHz)
C6-02=4
(10.0kHz)
C6-02=5
(12.5kHz)
C6-02=6
(15.0kHz)
CIPR-
GA50A

CIMR-
VA4A

0.2
4001
1.2
1.2
1.2
1.1
0.9
0.7
0001
1.2
1.2
1.2
1.1
0.9
0.7
0.4
4002
1.8
1.8
1.8
1.6
1.3
1.1
0002
1.8
1.8
1.8
1.6
1.3
1.1
0.75
4004
3.4
3.4
3.4
3.0
2.5
2.0
0004
3.4
3.4
3.4
3.0
2.5
2.0
1.5
4005
4.8
4.8
4.8
4.3
3.6
2.9
0005
4.8
4.8
4.8
4.3
3.6
2.9
2.2
4007
5.5
5.5
5.5
4.9
4.1
3.3
0007
5.5
5.5
5.5
4.9
4.1
3.3
3.0
4009
7.3
7.3
7.3
6.5
5.4
4.4
0009
7.2
7.2
7.2
6.4
5.3
4.3
3.7
4012
9.2
9.2
9.2
8.1
6.8
5.5
0011
9.2
9.2
9.2
8.1
6.8
5.5
5.5
4018
14.5
14.5
14.5
12.8
10.8
8.7
0018
14.8
14.8
14.8
13.1
11.0
8.9
7.5
4023
18.0
18.0
18.0
15.9
13.4
10.8
0023
18.0
18.0
18.0
15.9
13.4
10.8
11.0
4031
24.0
24.0
24.0
21.3
17.8
14.4
0031
24.0
24.0
24.0
21.3
17.8
14.4
15.0
4038
31.0
31.0
31.0
27.5
23.0
18.6
0038
31.0
31.0
31.0
27.5
23.0
18.6
18.5
4044
39.0
39.0
39.0
34.5
29.0
23.4
22.0
4060
45.0
45.0
45.0
39.9
33.4
27.0
