YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
2/35
1. Models to Be Replaced
Old model V1000
Type: CIMR-VAA
New model GA500
Catalog code: GA50A
Replacement Capacity 200 V Class (for three-phase power supply): 0.1 kW to 15 kW Heavy Duty Rating (HD)
0.2 kW to 18.5 kW Normal Duty Rating (ND)
(for single-phase power supply): 0.1 kW to 3.7 kW Heavy Duty Rating (HD)
0.2 kW to 5.5 kW Normal Duty Rating (ND)
400 V Class (for three-phase power supply): 0.2 kW to 15 kW Heavy Duty Rating (HD)
(for three-phase power supply): 0.4 kW to 18.5 kW Normal Duty Rating (ND)
The following table shows the matching between the old model (V1000) and replacement model type (GA500) numbers.
Differences in specification between the V1000 and the GA500 are highlighted in bold.
Table 1: 200 V Class (three-phase)
V1000
Model
Rated Output
Current
Normal Duty
(ND) Rating
Rated Output
Current
Heavy Duty
(HD) Rating
GA500
Catalog code
Rated Output
Current
Normal Duty
(ND) Rating
Rated Output
Current
Heavy Duty
(HD) Rating
CIMR-VA2A0001
1.2 A
0.8 A
GA50A2001
1.2 A
0.8 A
CIMR-VA2A0002
1.9 A
1.6 A
GA50A2002
1.9 A
1.6 A
CIMR-VA2A0004
3.5 A
3.0 A
GA50A2004
3.5 A
3.0 A
CIMR-VA2A0006
6.0 A
5.0 A
GA50A2006
6.0 A
5.0 A
CIMR-VA2A0008
8.0 A
6.9 A
GA50A2008
8.0 A
6.9 A
CIMR-VA2A0010
9.6 A
8.0 A
GA50A2010
9.6 A
8.0 A
CIMR-VA2A0012
12.0 A
11.0 A
GA50A2012
12.2 A
11.0 A
CIMR-VA2A0018
17.5 A
14.0 A
GA50A2018
17.5 A
14.0 A
CIMR-VA2A0020
21.0 A
17.6 A
GA50A2021
21.0 A
17.6 A
CIMR-VA2A0030
30.0 A
25.0 A
GA50A2030
30.0 A
25.0 A
CIMR-VA2A0040
40.0 A
33.0 A
GA50A2042
42.0 A
33.0 A
CIMR-VA2A0056
56.0 A
47.0 A
GA50A2056
56.0 A
47.0 A
CIMR-VA2A0069
69.0 A
60.0 A
GA50A2070
70.0 A
60.0 A
GA50A2082
82.0 A
75.0 A
Table 2: 200 V Class (single-phase)
V1000
Model
Rated Output
Current
Normal Duty
(ND) Rating
Rated Output
Current
Heavy Duty
(HD) Rating
GA500
Catalog code
Rated Output
Current
Normal Duty
(ND) Rating
Rated Output
Current
Heavy Duty
(HD) Rating
CIMR-VABA0001
1.2 A
0.8 A
GA50AB001
1.2 A
0.8 A
CIMR-VABA0002
1.9 A
1.6 A
GA50AB002
1.9 A
1.6 A
CIMR-VABA0004
3.3 A
3.0 A
GA50AB004
3.5 A
3.0 A
CIMR-VABA0006
6.0 A
5.0 A
GA50AB006
6.0 A
5.0 A
CIMR-VABA0010
9.6 A
8.0 A
GA50AB010
9.6 A
8.0 A
CIMR-VABA0012
12.0 A
11.0 A
GA50AB012
12.2 A
11.0 A
CIMR-VABA0018
-
17.5 A
GA50AB018
--
17.6 A

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
