YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
25/35
4-2. UL Type 1 Kit
The UL Type 1 kit model numbers are different between the V1000 and GA500.
Table 18 shows the GA500 attachment model numbers.
Table 18: UL Type 1 kit model numbers
4-3. External Cooling Fin Installation Attachment
This attachment is required to do an external cooling fin installation.
The attachment model numbers are different between the V1000 and GA500.
Table 19 shows the GA500 attachment model numbers.
Table 19: External Cooling Fin Installation Attachment model numbers
キット形式番号
2001-2006,B001,B002 ZBAA-GA50V1-1
B004
ZBAA-GA50V1-2
B006, 2012 ZBAA-GA50V2-1
B010, 4005-4009
ZBAA-GA50V2-2
2008, 2010
ZBAA-GA50V2-3
4001, 4002
ZBAA-GA50V2-4
4004
ZBAA-GA50V2-5
B012 ZBAA-GA50V3-1
2018, 2021, 4012
ZBAA-GA50V3-2
B018 ZBAA-GA50V4-1
2030, 2042, 4018, 4023 ZBAA-GA50V5-1
2056, 4031, 4038 ZBAA-GA50V6-1
2070, 2082 ZBAA-GA50V7-1
4044, 4060 ZBAA-GA50V8-1
インバータ形式
GA500
アタッチメント形式
三相200V級 単相200V級 三相400V級
2001, 2002 B001, B002 - ZPSA-GA50V1-1
2004 B004 - ZPSA-GA50V1-2
2006 - - ZPSA-GA50V1-3
- - 4001 ZPSA-GA50V2-1
- B006 4002, 4004 ZPSA-GA50V2-2
2008, 2010, 2010 B010 4005, 4007, 4009 ZPSA-GA50V2-3
2018, 2021 B012 4012 ZPSA-GA50V3-1
- B018 - EZZ02568F
2030, 2042 - 4018, 4023 ZPSA-GA50V5-1
2056 - 4031, 4038 ZPSA-GA50V6-1
2070, 2082 - - ZPSA-GA50V7-1
- - 4044, 4060 ZPSA-GA50V8-1
インバータ形式
Drive model type
Kit type number
Drive model type
Attachment type number
Three-phase 200 V class
Single-phase 200 V class
Three-phase 400 V class

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
