YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
21/35
Control circuit terminal sizes and wire gauges
Table 14: V1000 control circuit terminal sizes and wire gauges
Table 15: GA500 control circuit terminal sizes and wire gauges
Figure 16: Control circuit wiring procedure
 Wiring procedure
A - Loosen the screw to open the slot.
B - Insert a wire with a crimp ferrule attached or an unsoldered wire with the core wires lightly twisted.
 Processing wire ends
C - Pull back the shielding and lightly twist the end with your fingers to keep the ends from fraying.
D - Remove approximately 5.5 mm (0.21 in) of the shielding at the end of the wire if you do not use crimp ferrules.
 Screwdriver size
E - Blade width of 2.5 mm (0.1 in) or less
F - Blade thickness of 0.4 mm (0.01 in) or less
Terminal symbol
Screw
size
Tightening
torque
(N-m)
Stripped wire
Usable wire
Recommended
wire
Terminal symbol
Screw size
Tightening
torque
N-m (Ib., in)
Stripped wire
Usable wire
Recommended
wire
When using a crimp ferrule
Twisted wire 0.25 to 1.0
(24 to 17)
Single wire 0.25 to 1.5
(24 to 16)
Twisted wire 0.25 to 1.5
(24 to 16)
Single wire 0.25 to 1.5
(24 to 16)
Terminal
block
Recommended
wire size
Connectable wire
size
Recommended
wire size
Connectable wire
size
to
to
to
to
to
to
When using a crimp ferrule
 Twisted wire
0.25 to 1.0
(24 to 17)
 Single wire
0.25 to 1.5
(24 to 16)
 Twisted wire
0.25 to 1.0
(24 to 16)
 Single wire
0.25 to 1.5
(24 to 16)

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
