YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
28/35
Parameter
No.
Name
V1000
GA500
Default
Your
customized
settings
Range
Default
Range
b3-24
Speed
Search
Method
Selection
0
0 = Current Detection Type
1 = Speed Estimation
2
(Depends
on A1-02)
1 = Speed Estimation
Speed Search
2 = Current Detection
Speed Search
b8-01
Energy
Saving
Control
Selection
0
0 = Energy saving mode
disabled
1 = Energy saving mode
enabled
0
0 = Energy saving mode
disabled
1 = Energy saving mode
enabled
2 = PM energy saving
mode enabled
(Configurable only
when A1-02=6)
L2-01
Power Loss
Ride Through
Select
0
0 = Disabled
1 = Enabled
2 = Enabled while CPU
Power Active
0
0 = Disabled
1 = Enabled
2 = Enabled while CPU
Power Active
3 = KEB operation
4 = Kinetic Energy
Backup: CPU
Power
5 = Kinetic Energy
Backup: DecelStop
L3-01
Stall
Prevention
during Accel
1
0 = Disabled
1 = Enabled
2 = Intelligent (Ignore
Decel Ramp)
1
0 = Disabled
1 = Enabled
2 = Intelligent (Ignore
Decel Ramp)
3 = Current Limit
Method
L3-04
Stall
Prevention
during Decel
1
0 = Disabled
1 = General Purpose
2 = Intelligent (Ignore
Decel Ramp)
3 = General Purpose w/
DB resistor
4 = Overexcitation/High
Flux
7 = Overexcitation/High
Flux 3
1
0 = Disabled
1 = General Purpose
2 = Intelligent (Ignore
Decel Ramp)
3 = General Purpose w/
DB resistor
4 = Overexcitation/High
Flux 1
5 = Overexcitation/High
Flux 2
7 = Overexcitation/High
Flux 3
L3-05
Stall
Prevention
during RUN
1
0 = Disabled
1 = Deceleration Time 1
(C1-02)
2 = Deceleration Time 2
(C1-04)
0
* When
replacing
V1000
with
GA500,
set L3-
05=1.
0 = Disabled
1 = Deceleration Time 1
(C1-02)
2 = Deceleration Time 2
(C1-04)
3 = Intelligent
L8-40
Carrier Freq
Reduction
Off-Delay
0.50
0.00 to 2.00
0.50 for
A1-02=0
or 2
0.00 for
other
0.00 to 2.00 s
N1-01
Hunting
Prevention
Selection
1
0 = Hunting Prevention
disabled
1 = Hunting Prevention
enabled
1
0 = Hunting Prevention
disabled
1 = Hunting Prevention
enabled
2 = Hunting Prevention
enabled (for High
Carrier Frequency)
N3-02
HSB Current
Limit Level
150
100 to 200
Depends
on C6-01,
L8-38
0 to 200 %

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
