6 Related Drive Parameters
6 Related Drive Parameters
The parameters in Table 8 set the drive for operation with the option. Confirm proper setting
of all parameters in Table 8 before starting network communications. Refer to the manual
packaged with the drive for details on setting parameters.
Table 8 Related Parameter Settings
No.
(Addr. Hex)
Name Description Values
b1-01
(180)
<1>
Reference 1 Source
Selects the input method for frequency reference.
0: Keypad
1: Analog Input
2: Memobus/Modbus Communications
3: Option PCB
4: Pulse Train Input
Default: 1
Range: 0 to 4
(Set to 3)
b1-02
(181)
<1>
Run Command 1
Source
Selects the input method for the Run command.
0: Keypad
1: Digital Input
2: Memobus/Modbus Communications
3: Option PCB
Default: 1
Range: 0 to 3
(Set to 3)
F6-01
(3A2)
Communication Error
Selection
Selects drive response when a bUS error is detected during
communications with the option.
0: Ramp to Stop
1: Coast to Stop
2: Fast Stop (Use C1-09)
3: Alarm Only
<2>
4: Alarm - Run at d1-04
5: Alarm - Ramp to Stop
Default: 1
Range: 0 to 5
<3>
F6-02
(3A3)
Comm External Fault
(EF0) Detect
Selects the condition for external fault detection (EF0).
0: Always detected
1: Detection during run only
Default: 0
Range: 0, 1
F6-03
(3A4)
Comm External Fault
(EF0) Select
Selects drive response for external fault input (EF0)
detection during option communications.
0: Ramp to Stop
1: Coast to Stop
2: Fast Stop (Use C1-09)
3: Alarm Only
<2>
Default: 1
Range: 0 to 3
F6-07
(3A8)
MultiStep Ref Priority
Select
0: MultiStep References Disabled
1: MultiStep References Enabled
Default: 1
Range: 0, 1
F6-08
(36A)
Comm Parameter
Reset @Initialize
Selects whether communication-related parameters
F6- and F7- are set back to original default values
when the drive is initialized using parameter A1-03.
0: No Reset - Parameters retained
1: Reset - Back to factory default
Note: The setting value is not changed even when F6-08 is
set to 1 and the drive is initialized using A1-03.
Default: 0
Range: 0, 1
