Model CIMR-Zoo
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0156
<1>
R/L1, S/L2, T/L3 3 × 2
1/0 to 3/0 M8
13.5 to 15.0
(120 to 133)
U/T1, V/T2, W/T3 3 × 2
-M, +M –
–
4A0180
<1>
R/L1, S/L2, T/L3 2 × 2
1/0 to 3/0 M8
13.5 to 15.0
(120 to 133)
U/T1, V/T2, W/T3 2 × 2
-M, +M –
–
4A0240
<1>
R/L1, S/L2, T/L3 1/0 × 2
1/0 to 3/0 M8
13.5 to 15.0
(120 to 133)
U/T1, V/T2, W/T3 1/0 × 2
-M, +M –
–
4A0302
<1>
R/L1, S/L2, T/L3 3/0 × 2
1/0 to 4/0 M10
27.0 to 30.0
(239 to 266)
U/T1, V/T2, W/T3 3/0 × 2
-M, +M –
–
4A0361
<1>
R/L1, S/L2, T/L3 4/0 × 2 3/0 to 600
M12
32.0 to 40.0
(283 to 354)
U/T1, V/T2, W/T3 4/0 × 2 3/0 to 600
–, +1 – 4/0 to 600
+3 – 3/0 to 600 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
4A0414
<1>
R/L1, S/L2, T/L3 300 × 2 4/0 to 300
M12
32.0 to 40.0
(283 to 354)
U/T1, V/T2, W/T3 300 × 2 4/0 to 300
–, +1 – 3/0 to 300
+3 – 3/0 to 300
1 1 to 3/0
4A0480
<1>
R/L1, S/L2, T/L3 1/0 × 4
3/0 to 300 M12
32.0 to 40.0
(283 to 354)
U/T1, V/T2, W/T3 1/0 × 4
–, +1 –
+3 –
–
4A0515
<1>
R/L1, S/L2, T/L3 2/0 × 4
3/0 to 300 M12
32.0 to 40.0
(283 to 354)
U/T1, V/T2, W/T3 2/0 × 4
–, +1 –
+3 –
–
4A0590
<1>
R/L1, S/L2, T/L3 3/0 × 4
3/0 to 300 M12
32.0 to 40.0
(283 to 354)
U/T1, V/T2, W/T3 3/0 × 4
–, +1 –
+3 –
–
<1>
Drive models CIMR-Zo4A0034 to 4A0590 require the use of closed-loop crimp terminals for UL/cUL compliance. Use only the tools recommended
by the terminal manufacturer for crimping.
uu
Main Circuit Terminal and Motor Wiring
This section outlines the various steps, precautions, and checkpoints for wiring the main circuit terminals and motor terminals.
WARNING! Electrical Shock Hazard. Do not connect the AC power line to the output terminals of the drive. Failure to comply could result
in death or serious injury by fire as a result of drive damage from line voltage application to output terminals.
3.8 Main Circuit Wiring
82
YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual
