YASKAWA Z1000 User's Manual Supplement

13 Replace Table D.5 on page 336
Table D.5 Factory Recommended Z1000 AC Drive Branch Circuit Protection
Model CIMR-Zoo
Nominal Output
Power (HP)
AC Drive Input
(A)
MCCB Rating (A)
<1>
Time Delay Fuse
Rating (A)
<2>
Non-time Delay
Fuse Rating (A)
<3>
Bussmann
Semiconductor
Fuse Model
(Fuse Ampere)
<4>
200 V Class
2A0011 3 10.6 20 17.5 30 FWH-40B (40)
2A0017 5 16.7 30 25 50 FWH-50B (50)
2A0024 7.5 24.2 40 40 70 FWH-80B (80)
2A0031 10 30.8 60 50 90 FWH-100B (100)
2A0046 15 46.2 90 80 125 FWH-150B (150)
2A0059 20 59.4 110 100 175 FWH-175B (175)
2A0075 25 74.8 150 125 200 FWH-225A (225)
2A0088 30 88 175 150 250 FWH-225A (225)
2A0114 40 114 225 175 300 FWH-250A (250)
2A0143 50 143 250 250 400 FWH-275A (275)
2A0169 60 169 300 275 500 FWH-350A (350)
2A0211 75 211 400 350 600 FWH-400A (400)
2A0273 10 273 500 450
<5>
FWH-450A (450)
2A0343 125 343 600 600 FWH-600A (600)
2A0396 150 396 700
<5>
FWH-600A (600)
400 V Class
4A0005 3 4.8 15 8 12 FWH-40B (40)
4A0008 5 7.6 15 12 20 FWH-40B (40)
4A0011 7.5 11 20 17.5 30 FWH-45B (45)
4A0014 10 14 25 20 40 FWH-45B (45)
4A0021 15 21 40 35 60 FWH-60B (60)
4A0027 20 27 50 45 80 FWH-60B (60)
4A0034 25 34 60 50 100 FWH-125B(125)
4A0040 30 40 75 70 110 FWH-150B (150)
4A0052 40 52 100 90 150 FWH-200B (200)
4A0065 50 65 125 110 175 FWH-225A (225)
4A0077 60 77 150 125 225 FWH-225A (225)
4A0096 75 96 175 150 275 FWH-225A (225)
4A0124 100 124 225 200 350 FWH-250A(250)
4A0156 125 156 300 250 450 FWH-300A (300)
4A0180 150 180 350 300 500 FWH-350A (350)
4A0240 200 240 450 400
<5>
FWH-400A (400)
4A0302 250 302 600 500 FWH-600A (600)
4A0361 300 346 600
600 1000
<6>
FWH-800A (800)
4A0414 350 410 800 700
1200
<6>
FWH-800A (800)
4A0480 400 480 900
<5> <5>
FWH-700A (700)
4A0515 450 515 1000 FWH-800A (800)
4A0590 500 590 1100 FWH-1000A (1000)
<1> Maximum MCCB rating is 15 A, or 200% of drive input current rating, whichever value is larger. MCCB voltage rating must be 600 Vac or greater.
<2> Maximum Time delay fuse is 175% or drive input current rating. This covers any Class J, T, or CC fuse.
<3> Maximum Non-time delay fuse is 300% of drive input current rating. This covers any Class J, T, or CC fuse.
<4> When using semiconductor fuses, Bussmann FWH fuses are required for UL compliance.
<5> Consult factory.
<6> Class L fuse is also approved for this rating.
D.3 UL/cUL Standards
350
YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual
13 Replace Table D.5 on page 336
YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement
23

YASKAWA Z1000 Specifications

General

Model	Z1000
Category	Controller
Humidity	95% RH or less (non-condensing)
Control Method	V/F Control
Frequency Range	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Altitude	Up to 1000 meters without derating
Cooling Method	Forced Air
Enclosure Rating	IP20
Voltage Class	200V, 400V
