Model CIMR-Zoo
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
2A0396 FWH-600A 600
Three-Phase 400 V Class
4A0005 FWH-40B 40
4A0008 FWH-40B 40
4A0011 FWH-45B 45
4A0014 FWH-45B 45
4A0021 FWH-60B 60
4A0027 FWH-60B 60
4A0034 FWH-125B 125
4A0040 FWH-150B 150
4A0052 FWH-200B 200
4A0065 FWH-225A 225
4A0077 FWH-225A 225
4A0096 FWH-225A 225
4A0124 FWH-250A 250
4A0156 FWH-300A 300
4A0180 FWH-350A 350
4A0240 FWH-400A 400
4A0302 FWH-600A 600
4A0361 FWH-800A 800
4A0414 FWH-800A 800
4A0480 FWH-700A 700
4A0515 FWH-800A 800
4A0590 FWH-1000A 1000
nn
Guarding Against Harmful Materials
When installing IP00/Open Type enclosure drives, use an enclosure that prevents foreign material from entering the drive
from above or below.
nn
Grounding
The drive is designed to be used in T-N (grounded neutral point) networks. If installing the drive in other types of grounded
systems, contact your Yaskawa representative for instructions.
uu
EMC Guidelines Compliance
This drive is tested according to European standards EN61800-3: 2004.
nn
EMC Filter Installation
Note:
Drive models CIMR-Zo2A0011 to 2A0273 and 4A0005 to 4A0302 have a built-in EMC filter.
The following conditions must be met to ensure continued compliance with guidelines. Refer to EMC Filters on page 347
for EMC filter selection.
Installation Method for CIMR-Zoo2A0011 to 2A0273 and 4A0005 to 4A0302
Verify the following installation conditions to ensure that other devices and machinery used with this drive comply with EMC
guidelines.
1.
Move the screws to the ON position to enable the internal EMC filter.
2.
Use braided shield cable for the drive and motor wiring, or run the wiring through a metal conduit.
3.
Keep wiring as short as possible. Ground the shield on both the drive side and the motor side.
Installation Method for CIMR-Zoo2A0343, 2A0396, and 4A0361 to 4A0590
Verify the following installation conditions to ensure that other devices and machinery used in combination with this drive
also comply with EMC guidelines.
1.
Install an EMC noise filter to the input side specified by Yaskawa for compliance with European standards.
D.2 European Standards
YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual
343
D
Standards Compliance
