Table 2.8 Dimensions for IP00/Open-Type Enclosure: 200 V Class
Drive
Model
CIMR-Zoo
Figure
Dimensions (in)
Screw
Size
Wt. (lb)
W H D W1 W2 W3 H1 H2 D1 t1 d
2A0343A
1
19.69 31.50 13.78 14.57 0.30 30.43 0.51 5.12 0.18 M12 216.1
2A0396A 19.69 31.50 13.78 14.57 0.30 30.43 0.51 5.12 0.18 M12 218.3
Table 2.9 Dimensions for IP00/Open-Type Enclosure: 400 V Class
Drive
Model
CIMR-Zoo
Figure
Dimensions (in)
Screw
Size
Wt. (lb)
W H D W1 W2 W3 H1 H2 D1 t1 t2 d
4A0361A 2 19.69 31.50 13.78 14.57 0.39 30.43 0.51 5.12 0.18 0.18 M12 235.9
4A0414A 4 19.69 37.40 14.57 14.57 0.31 36.34 0.51 5.31 0.18 0.18 M12 476.2
4A0480A
3
26.38 44.88 14.57 17.32 0.24 8.66 43.70 0.59 5.91 0.18 M12 476.2
4A0515A 26.38 44.88 14.57 17.32 0.24 8.66 43.70 0.59 5.91 0.18 M12 487.2
4A0590A 26.38 44.88 14.57 17.32 0.24 8.66 43.70 0.59 5.91 0.18 M12 487.2
2.2 Mechanical Installation
YASKAWA ELECTRIC TOEP C710616 45B YASKAWA AC Drive – Z1000 User Manual
53
2
Mechanical Installation
4 Replace pages 51 and 52
YASKAWA TOEP YAISUP 04A YASKAWA AC Drive – Z1000 User Manual Supplement
9
